Rated to suit motors and Trip Class Ratings:-
30kW, 55A at 400V - Trip Class 10.
22kW, 47A at 400V - Trip Class 20.
​18.5kW, 35A at 400V - Trip Class 30. See trip guide below.

Can also be used on 230V 3 phase and 500V supplies. See manual for details.

Up to 5 starts per hour as standard, Up to 40 starts per hour if optional fan is fitted - see linked products for details.

Main Circuit IP00 (IP20 with optional finger guard, see linked products below). Control Circuit IP20.

Frame 1 Dimensions: 165mm high x 108mm wide x 148mm deep.
Weight: 1.97kg.

Features include:
Integrated Keypad with Display.
Internal bypass.
2 x Digital Inputs, 1 x Run Relay, 1 x Fault Relay.
USB terminal for firmware upgrades and data logging.
Modbus RTU Fieldbus communications port built in.

Input Voltage: 200Vac to 600Vac, at 50/60Hz +/- 10%
Supply fuse rating 160A, semiconductor fuse aR type - see linked product below.
Requires external power supply (not included, see linked products below) or compatible 24V 2A DC supply for operation.

Cubicle mount.
Ventilation space above and below: 75mm
Ventilation space at sides: 25mm (each side)
Ventilation space in front: 25mm
Mounting via 4 bolts at rear on 165mm x 90mm centres.
Operating Temp: -20°C to 40°C. Above 40°C derate linearly by 2% per °C to a maximum of 60°C
Heat loss: 25W.
