Microsonic SyncBox1 mic+

For the external synchronization of more than 10 mic+ sensors. The SyncBox1 allows synchronization of up to 160 mic+ sensors....

Brand: Microsonic
Šifra: SyncBox1
Dostupnost: Proveriti dostupnost
Cena na upit
For the external synchronization of more than 10 mic+ sensors. The SyncBox1 allows synchronization of up to 160 mic+ sensors.
cylindrical M30
accessories
For the external synchronization of more than 10 mic+ sensors. The SyncBox1 allows synchronization of up to 160 mic+ sensors.
9 - 30 V d.c., reverse polarity protection
± 10 %
≤ 25 mA
5-pin M12 initiator plug
synchronisation output
npn: Imax = 200 mA (-UB+2V)
synchronisation output
npn: Imax = 200 mA (-UB+2V)
control input
brass sleeve, nickel-plated, plastic parts, PBT
IP 67
-20°C to +70°C
-40°C to +85°C
110 g
2 push-buttons + LED display (TouchControl)
TouchControl
3-digit LED display, 2 x three-colour LED

  • ba eng syncbox1

    ba eng syncbox1
