Microsonic SyncBox2 zws
Unit for synchronisation of ultrasonic sensors from the zws range...
Cena na upit
Unit for synchronisation of ultrasonic sensors from the zws range
cuboidal
accessories
20 - 30 V d.c., reverse polarity protection
± 10 %
≤ 25 mA
4-pin M8 initiator plug
synchronisation output
npn: Imax = 200 mA (-UB+2V)
npn: Imax = 200 mA (-UB+2V)
control input
ABS
IP 67
-20°C to +70°C
-40°C to +85°C
10 g
1 push-button
1 x LED green: working, 1 x LED yellow: reputation rate
-
ba eng syncbox2
