SIMATIC HMI Basic Panel - Cost-effective operation and monitoring in the second generation
SIMATIC Basic Panels 2nd Generation are suitable for cost-effective implementation of simple visualization tasks on the machine level.
Siemens SIMATIC HMI TP400 Basic; 6AV2143-6DB00-0AA0
SIMATIC HMI, TP400 Basic Keyless; Basic Panel, neutral design, touch operation, 4" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic
-
(Trenutno nema na stanju)
46.203,05
Siemens SIMATIC HMI KTP400 Basic; 6AV2123-2DB03-0AX0
SIMATIC HMI, KTP400 Basic, Basic Panel, Key/touch operation, 4" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic
-
(Trenutno nema na stanju)
48.201,65
Siemens SIMATIC HMI KTP700 Basic; 6AV2123-2GB03-0AX0
SIMATIC HMI, KTP700 Basic, Basic Panel, Key/touch operation, 7" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic
-
(Trenutno nema na stanju)
87.617,67
Siemens SIMATIC HMI TP700 Basic; 6AV2143-6GB00-0AA0
SIMATIC HMI, TP700 Basic Keyless; Basic Panel, neutral design, touch operation, 7" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic
-
(Na stanju)
93.450,07
Siemens SIMATIC HMI KTP900 Basic; 6AV2123-2JB03-0AX0
SIMATIC HMI, KTP900 Basic, Basic Panel, Key/touch operation, 9" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic
-
(Trenutno nema na stanju)
152.839,20
Siemens SIMATIC HMI KTP1200 Basic; 6AV2123-2MB03-0AX0
SIMATIC HMI, KTP1200 Basic, Basic Panel, Key/touch operation, 12" TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic
-
(Na stanju)
218.732,03
SIMATIC HMI Basic Panel - Cost-effective operation and monitoring in the second generation
SIMATIC Basic Panel 2nd Generation
Cost-effective operation and monitoring in the second generation
SIMATIC Basic Panels 2nd Generation are suitable for cost-effective implementation of simple visualization tasks on the machine level. Their basic features and
functionality as well as an attractive price make them perfect entry-level devices.
The Basic Panels 2nd Generation are suited for simple applications, compact systems and smaller applications with a limited configuration scale, where fast and intuitive
operation is as important as the price-performance ratio.
Highlights
Improved process quality of compact systems and smaller applications through visualization
• Integration of all important HMI basic functions thus opens up new possibilities for operating and monitoring in mechanical engineering at an especially attractive price.
• Standard integration of numerous software functions, such as alarm system, recipe management, trend functionality and language switching.
• Improved usability through new controls and graphics.
High degree of user-friendliness thanks to innovative graphical user interface
• User-friendly touch screens and especially practical, freely configurable keys.
• Integrated USB interface for connecting keyboard, mouse or barcode scanner and easy archiving of data on USB stick.
• Connection to various PLCs by integrating PROFIBUS and PROFINET interfaces.
• Visualization of applications of the modular, compact SIMATIC S7-1200 controllers.
Efficient engineering ensures cost and time savings
• Integrated engineering framework for controllers, HMIs and drives in the TIA Portal.
High Resolution Widescreen Displays
• Optional use of high resolution widescreen displays from 4" - 12". These can be installed in traditional horizontal format as well as vertical; the configuration software
supports both installation alternatives.
• Improved process representation is possible thanks to the high resolution and the color depth of 64,000 colors. The brightness of the displays can be dimmed to 100%
and thus offers optimum flexibility.
Scalable software for easy configuration
• The configuration is performed with SIMATIC WinCC (TIA Portal) in the inexpensive basic version. The intuitive usability and unique configuration efficiency of the
engineering framework is provided even in this version.
• As requirements increase, projects created for a Basic Panel can be easily transferred to devices of other performance classes or display sizes.
